Samsung QB13R - 13-inch EDGE LED FHD Display, 300 NIT
Enhanced communication in a compact display
Overview:
Businesses no longer just need large size displays, they often also need smaller displays for a variety of environments and uses. Samsung’s QB13R / QB13R-T small display enables personalized and more impactful communication through its compact and versatile design. An all-in-one solution designed for professional use, the display improves the operational effi ciency of content, while also ensuring reliable performance for any business use. The QB13R-T specifi cally, is a touch-enabled small display which provides a unique store experience and improves customer engagement.
- 13” FHD, non-glare display delivering clear content.
- Compact and slim design enabling effi cient use of space.
- Embedded MagicINFO S player to support seamless content playback.
- Rigid 3-layered Knox security system preventing any unauthorized access.
- Center IR and built-in Wi-Fi allowing convenient remote device control and management.
- EMC Class B and IP5x rating to ensure safe and reliable operation.
Industry trend
As creating differentiated brick-and-mortar locations continues to increase in popularity, providing a unique in-store experience is critically important for elevating a brand and driving sales. Therefore, businesses are finding new and effective ways to engage customers by making the most of every customer touch point. That means small sized displays are being adapted as common tools within various environments. More personalized, intimate content can reach the right audience at optimal points in time, increasing engagement and sales opportunities. Efficient content management and reliable performance ensure businesses can operate the displays without any hassle.
Introducing Samsung Small Displays
Samsung is introducing the two latest versatile, small sized displays, the QB13R and touch-enabled QB13R-T. Designed for professional use, Samsung’s QB13R Series delivers clear content using the embedded MagicINFO S media player, supported by reliable 16/7 operation and industry standard certification to ensure safe operation, reliable performance and eliminate any hassle.
QB13R : Small Display
The QB13R, FHD resolution display delivers clear and vibrant content, all in a slim and compact design. It can easily be applied to any business environment, such as a tool to display schedules, information and promotions in corporate lobbies, elevators and in front of meeting rooms and classrooms. To engage customers more directly, the QB13R can also be used as a store shelf display to promote a specific or targeted item, in addition to showing promotions at the point of sale (POS) or counter.
QB13R-T : Touch Display
With integrated capacitive touch functionality, the QB13R-T provides a user-friendly experience. Its 10-point multi-touch and fast response time powers an intuitive interface that allows for customer-driven search and action. QB13R-T is optimized for any interaction opportunities such as healthcare, check-in at the gym, an automotive showroom, as well as any retail or restaurant environment where businesses would want to offer a personalized service while also acquiring customer data.
Features:
Crisp and visible content
The display supports 1920x1080 FHD resolution, displaying crisp and easy-to-read content. This is enhanced by a non-glare panel which always delivers clear content in any ambient light. These innovative features are supported by reliable 16/7 operation, suitable for professional use.
Slim, smart design
The compact and slim design of the QB13R allows for effi cient space utilization, even in compact locations. A sleek back design makes the display optimal for both wall mounting or simply standing, while the connectivity, content play and device controls are easy to operate.
Powerful content playback
With an embedded MagicINFO S player, backed by TIZEN, the QB13R allows effi cient and seamless playback without any external media player. SSSP also allows easy content development through reinforced compatibility with multiple web formats.
Comprehensive security setup
The powerful Knox security system provides rigid, three-layer security, offering airtight protection at the application, platform and system level, while restricting access to content and hardware. In addition, remote control of the network and USB ports prevents any unauthorized access.
Convenient, clean display control
With center IR, each display receives IR signals direct to the panel, allowing easy and convenient remote control even with a tailored installation. When mounted, display doesn’t require an IR receiver cabling extension. Built-in Wi-Fi allows wireless remote management for both content and display.
Safe operation, reliable performance
The QB13R is electromagnetic compatibility (EMC) class B compliant, meeting strict safety and reliability standards for operation. Additionally, IP5x rating ensures durable performance even in dusty environments.
Specifications:
| Model | QB13R | QB13R-T | ||
|---|---|---|---|---|
| Panel | Diagonal Size | Class | 13" | 13" |
| Measured | 13.27" | 13.27" | ||
| Type | Edge LED | Edge LED | ||
| Resolution | FHD (1920 x 1080) | FHD (1920 x 1080) | ||
| Pixel Pitch (mm) | 0.153 x 0.153 | 0.153 x 0.153 | ||
| Active Display Area | 293.76 (H) x 165.24 (V) | 293.76 (H) x 165.24 (V) | ||
| Brightness(Typ.) | 300nit | 250nit | ||
| Contrast Ratio (Typ.) | 800:1 | 600:1 | ||
| Viewing Angle(H/V) | 178/178 | 178/178 | ||
| Response Time (G to G) | 8ms(Typ.) | 8ms(Typ.) | ||
| Display Colors | 16.7 M (real 6bit, dither 8bit) | 16.7 M (real 6bit, dither 8bit) | ||
| Color Gamut | 45% | 45% | ||
| Operation Hour | 16/7 | 16/7 | ||
| Haze | 10% | 10% | ||
| Display | Dynamic C/R | MEGA | MEGA | |
| H-Scanning Frequency | 30 ~ 81kHZ | 30 ~ 81kHZ | ||
| V-Scanning Frequency | 48 ~ 75HZ | 48 ~ 75HZ | ||
| Maximum Pixel Frequency | 594MHz | 594MHz | ||
| Sound | Speaker Type | Built in Speaker(5W) | Built in Speaker(5W) | |
| Connectivity | INPUT | RGB | - | - |
| VIDEO | HDMI 1.4 (1) | HDMI 1.4 (1) | ||
| HDCP | HDCP 2.2 | HDCP 2.2 | ||
| AUDIO | N/A | N/A | ||
| USB | USB 2.0 x 1 | USB 2.0 x 1 | ||
| OUTPUT | RGB | N/A | N/A | |
| VIDEO | N/A | N/A | ||
| AUDIO | Stereo Mini Jack | Stereo Mini Jack | ||
| Power Out | N/A | N/A | ||
| USB | N/A | N/A | ||
| EXTERNAL CONTROL | RS232C(in) thru stereo jack, RJ45 | RS232C(in) thru stereo jack, RJ45 | ||
| EXTERNAL SENSOR | N/A | N/A | ||
| Tuner | N/A | N/A | ||
| Power | Type | Adapter | Adapter | |
| Power Supply | AC 100 - 240 V~ (+/- 10 %), 50/60 Hz | AC 100 - 240 V~ (+/- 10 %), 50/60 Hz | ||
| Power Consumption | Max[W/h] | 27.5 | 27.5 | |
| Typical[W/h] | 13 | 14 | ||
| Rating[W/h] | 25 | 25 | ||
| BTU(Max) | 93.8 | 93.8 | ||
| Sleep mode | 0.5 | 0.5 | ||
| Off mode | N/A | N/A | ||
| Mechanical Spec | Dimension(mm) | Set | 322.0x193.5x28.2 | 322.0x193.5x29.8 |
| Package | 376x132x248 | 376x132x248 | ||
| Weight (kg) | Set | 0.9 | 1.1 | |
| Package | 1.7 | 2.0 | ||
| VESA Mount | 100 X 100 | 100 X 100 | ||
| Protection Glass | N/A | N/A | ||
| Stand Type | Bar Type Simple Stand (Inbox) | Bar Type Simple Stand (Inbox) | ||
| Bezel Width (Top/Side/Bot) (mm) | 12.2mm | 13.1mm | ||
| Operation | Operating Temperature | 0℃~ 40℃ | 0℃~ 40℃ | |
| Humidity | 10~80% | 10~80% | ||
| Feature | Key | Small Signage Display, Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0 | Small Touch Signage Display , Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0 | |
| Special | H/W | Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(5W 1ch), IP5x Rating, Wi-Fi | Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(5W 1ch), IP5x Rating, Wi-Fi, 10 Point Touch(Max) | |
| S/W | Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting) | Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting) | ||
| Internal Player (Embedded H/W) | Processor | Cortex A72 1.7GHz Quad-Core CPU | Cortex A72 1.7GHz Quad-Core CPU | |
| On-Chip Cache Memory | L1 Instruction Cache : 48KB, L1 Data Cache : 32KB, L2 Cache : 2MB | L1 Instruction Cache : 48KB, L1 Data Cache : 32KB, L2 Cache : 2MB | ||
| Clock Speed | 1.7GHz | 1.7GHz | ||
| Main Memory Interface | 2.5GB, LPDDR4 1.5GHz 64bit | 2.5GB, LPDDR4 1.5GHz 64bit | ||
| Graphics | Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.) |
Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.) |
||
| Storage (FDM) | 8GB (3.88GB Occupied by O/S, 4.12GB Available) | 8GB (3.88GB Occupied by O/S, 4.12GB Available) | ||
| Multimedia | *Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG | *Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG | ||
| IO Ports | USB 2.0 | USB 2.0 | ||
| Operating System | Tizen 4.0 (VDLinux) | Tizen 4.0 (VDLinux) | ||
| Certification | Safety | 60950-1 | 60950-1 | |
| EMC | Class B | Class B | ||
| Environment | ENERGY STAR 8.0, Epeat | ENERGY STAR 8.0, Epeat | ||
| Accessories | Included | Quick Setup Guide, Warranty Card,Power Cord, Remote Controller, Batteries, Bar Type Simple Stand | Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries, Bar Type Simple Stand, USB Cable | |
| Optional | Stand | Bar Type Simple Stand(inbox) | Bar Type Simple Stand(inbox) | |
| Mount | - | - | ||
| Specialty | - | - | ||
| Media Player | N/A | N/A | ||
Images:
Documentation:
Download the Samsung SMART Signage Small Display Series Datasheet (.PDF)
