Samsung UD46E-A - UD-E-A Series 46" Direct-Lit LED Display
Daisy chain multiple displays with Display Port 1.2 digital loop-out to achieve 4K UHD (3840x2160) resolution.

Samsung UD46E-A - UD-E-A Series 46" Direct-Lit LED Display


Sorry, This product is no longer available, please Contact Us for a replacement.

Overview:

Create beautiful video walls in an affordable fashion. The UD46E-A features an ultra-thin bezel for virtually seamless matrices. Factory calibration provides brightness and color uniformity across multiple displays. And you can achieve 4K UHD resolution when you daisy chain multiple displays with the Display Port 1.2 digital loop-out feature, without the cost of external processing scalers and distribution boxes.

  • Daisy chain multiple displays with Display Port 1.2 digital loop-out to achieve 4K UHD (3840x2160) resolution
  • Ultra-narrow bezels at 3.5mm bezel-to-bezel (BtB) allow you to create virtually seamless video walls
  • Factory-tuned for brightness and color uniformity right out of the box, with Advanced Color Management for customization
  • Cost-effective video wall display solution built for 24/7 around the clock operation

Features

Factory Calibration

Samsung's factory calibration ColorExpert technology helps to minimize color difference across mulitple displays. Factory-tuned for brightness, color temperature and gamma, you can experience color uniformity right out of the box for consistent video wall matrices.

Advanced Color Management (ACM)

The ACM solution provides a user-friendly interface to implement customized and detailed color adjustments. Fine-tune luminance, temperature and gamma through auto calibration, manual calibration and duplication to achieve the perfect display for your business.

Ultra-Narrow 3.5mm Bezels

The UD46E-A features incredibly thin bezels at a mere 3.5mm bezel-to-bezel. So you can create virtually seamless video walls with elegance and sophistication.

Beautiful Video Walls

Create elaborate, stunning video walls. And when you daisy chain multiple displays with the Display Port 1.2 digital loop-out feature, you can achieve 4K UHD (3840x2160) resolution. So you can deliver exceptional content with fine detail for a stunning, impactful experience.

Image Rotation

Enjoy convenient content creation and management. Create your desired content on a single display and turn on Image Rotation to transform portrait orientation into horizontal, and vice versa, when you connect and split-screen multiple displays in a video wall matrix.

Magic Clone

Save installation time for multiple displays with Magic Clone. Simply enter your display settings the first time, save the setting information to a USB or external HDD and plug in the external device to the other sets to install them equally.

Specifications:

Samsung UD46E-A - UD-E-A Series 46" Direct-Lit LED Display Specifications
Display
Screen Size 46"
Panel Technology D-LED DID
Resolution 1920 x 1080
Brightness Max 700 nits
Contrast Ratio (Typical) 3500:1
Viewing Angle (H/V) 178°/178°
Response Time 8ms
Connectivity
Input RGB: Analog D-SUB, DVI-D, Display Port 1.2, VIDEO: HDMI1,HDMI2, AUDIO: Stereo mini Jack, USB: Only for F/W upgrades
Output RGB: DP1.2(Loop-out), AUDIO: Stereo mini Jack
External Control RS232C(in/out), RJ45
External Sensor Detachable type(IR, Ambient)
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max) 128W / 187W
Power Consumption (Standby) < 0.5W
Features
Special Hardware: Haze 44%, Temperature Sensor, RS232C/RJ45 MDC,Plug and Play (DDC2B), Video Wall(OSD), Video Wall Daisy Chain, Pivot Display, Button Lock, DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support), Clock Battery(80hrs Clock Keeping)
Software: ACM Support(Advanced Color Management), Auto Source Switching & Recovery, Image Rotation, Smart F/W update,
Vesa Standard Wall-Mount Interface 600 x 400 mm
24/7 Operation Yes
Video Wall/Thin Bezel Yes
Dimensions
Without Stand (W x H x D) 40.3" x 22.8" x 3.8"
Packaging (W x H x D) 49.4" x 31.4" x 14.0"
Bezel Width 2.3mm(U/L), 1.2mm(R/B)
Weight
Product Weight 39.7 lb.
Product Weight 49.4 lb.
Included in Box
Included in Box Quick Setup Guide, Warranty Card, DP cable, stereo to DB9 cable, Power Cord, Remote Controller, Batteries
Optional Wall Mount Kit WMN-46VD
Optional Stand MID-UD46DS
Optional Media Player SBB (Optional, SIM Type) Signage Player Box (SBB-SS08EL1)
Green Management
Emission Standard EMC
Energy Star 6.0 Compliant ENERGY STAR 6.0 (USA)
ROHS Compliant Yes
Packaging Recyclability Yes, Packing Materials
Operation
Operating Temperature 0℃~ 40℃
Operating Humidity 10~80%
Warranty
Warranty 3 Years On-Site Parts and Labor

Documentation:

Download the Samsung UD46E-A - UD-E-A Series Datasheet (.PDF)
